REF 20.99.2R
  • Traverse mit Lasthebemagneten
  • Magnettraverse BHP
  • Lasthebemagnet mit Traverse
  • 20-06-pep-magnet-braillon-with-beam-palonnier-37106
Traverse mit LasthebemagnetenMagnettraverse BHPLasthebemagnet mit Traverse20-06-pep-magnet-braillon-with-beam-palonnier-37106

Lifting Beam with 2 Hooks

    • Heavy duty construction
    • Safe
    • Effective

. Hook distance adjustment with top handles every 100 mm
. 2 turning hooks with safety locks
. Anticorrosive paint
. Capacity 1 - 10 T
. Length from 2 to 5 m


  • Use :
    • Lifting
    • Handling
Options :
- Other sizes on request
spreader beam

Qty Product Weight in kg A B C D E F G H
20.99.2R.1000.2M6420001000210060801005101000 kg
20.99.2R.1000.3M10030001000310060801005301000 kg
20.99.2R.1000.4M12740002000410060801005301000 kg
20.99.2R.2000.2M77200010002100801201004702000 kg
20.99.2R.3000.2M1052000100021501001801005803000 kg
20.99.2R.4000.2M1202000100021501001801006504000 kg
20.99.2R.5000.2M1352000100021501001801006705000 kg
20.99.2R.6000.2M1652000100022001001801006906000 kg
20.99.2R.8000.2M1952000100022001001801007708000 kg
20.99.2R.10000.2M22020001000220010018010079010.000 kg
indication_tableau_dessus
